Aluminum strip for transformer
Transformer aluminum strip is the key raw material for manufacturing transformer windings. Aluminum strip is a strip obtained by rolling aluminum ingots, and has a thickness close to that of aluminum coils. Aluminum trip for transformer is mostly made of pure aluminum, which can have higher conductivity and corrosion resistance, such as 1060, 1050, 1050A, 1070, 1070A, 1350 and other alloys. Transformer aluminum strip is a metal product specially used for manufacturing transformers. It has excellent electrical conductivity and processing performance. At present, the most commonly used material for transformer strips is aluminum strip.
Aluminum strip for transformer
Transformer aluminum strip alloy specifications
The common alloy for transformer aluminum strips is 1000 series aluminum grade with higher purity. In addition to the 1xxx series, there are other series of aluminum alloys that can be used for transformer aluminum strips.
| Alloy Series | Grade | Features |
| 1000 series aluminum strip | 1050,1060,1070,1100,1350 | 1000 sereis has good plasticity and high processability, and is easy to carry out processing operations such as rolling, stretching and extrusion. |
| 3000 series aluminum strip | 3003,3004 | The 3xxx series adds manganese element, and the 3000 series aluminum strip has high strength and corrosion resistance. |
| 5000 series aluminum strip | 5005,5052 | The main element of 5000 series aluminum strip is magnesium, which has high strength and tensile properties, can withstand large pressure and tension, and has very good ductility. |
| 8000 series aluminum strip | 8011,8021 | 8000 series aluminum strips have excellent creep resistance, high temperature resistance stability, tensile strength, electrical conductivity and corrosion resistance. |
Why choose aluminum strip for transformer?
Using aluminum strip as transformer material has many advantages that cannot be replaced by other metals:
aluminum strip for transformer
1. Aluminum strip has strong electrical conductivity: As a raw material for transformer windings, aluminum strip can provide good current conduction and effectively reduce current loss.
2. Aluminum strip is light in weight and high in strength: Aluminum strip is light in texture and moderate in strength, making it easy to transport and install. It can also meet the mechanical requirements of the transformer during operation.
3. Low cost of aluminum strip: As aluminum is a widely used metal material, the manufacturing cost of aluminum strip transformers is also relatively low.
4. Easy processing: Aluminum strips have good plasticity and processing properties and can be easily processed into various specifications and shapes to meet the needs of different transformer designs.
5. Aluminum strip has excellent corrosion resistance: A dense oxide film is easily formed on the surface of the aluminum strip, which has good corrosion resistance and can ensure long-term stable operation of the transformer.
Aluminum strips as a transformer material have both advantages and limitations. Huawei Aluminum can provide the most suitable aluminum strip products according to your production needs.
Specification tolerances of transformer aluminum strips
| Aluminum Strip For Transformer Tolerance | |||||
| Thickness | 0.2-0.4 | 0.4-0.8 | 0.9-1.1 | 1.2-1.6 | 1.8-2.5 |
| Tolerance | ±0.01 | ±0.015 | ±0.02 | ±0.025 | ±0.03 |
| Width | 100 | 100-200 | 201-500 | 501-1250 | 1250 |
| Tolerance | ±0.1 | ±0.2 | ±0.2 | ±1 | ±2 |
Pure aluminum strip for transformer chemical element
| 1050 pure aluminum strip chemical composition(%) | |||||||||
| Element | Al | Si | Fe | Mg | Zn | Mn | Ti | Cu | V |
| Content | ≥99.5 | 0.0431 | 0.203 | 0.0013 | 0.0093 | 0.0104 | 0.02 | 0.0022 | 0.0039 |
| 1060 pure aluminum strip chemical composition(%) | |||||||||
| Element | Al | Si | Fe | Mg | Zn | Mn | Ti | Cu | V |
| Content | ≥99.6 | 0.0431 | 0.203 | 0.0013 | 0.0093 | 0.0104 | 0.02 | 0.0022 | 0.0039 |
| 1070 pure aluminum strip chemical composition(%) | |||||||||
| Element | Al | Si | Fe | Mg | Zn | Mn | Ti | Cu | V |
| Content | ≥99.7 | 0.0431 | 0.203 | 0.0013 | 0.0093 | 0.0104 | 0.02 | 0.0022 | 0.0039 |
| 1350 pure aluminum strip chemical composition(%) | |||||||||
| Element | Al | Si | Fe | Mg | Zn | Mn | Ti | Cu | V |
| Content | ≥99.5 | 0.0431 | 0.203 | 0.0013 | 0.0093 | 0.0104 | 0.02 | 0.0022 | 0.0039 |
